Battery Energy Storage Solution - C&I
Control And Monitoring With Modbus Tcp/ip & Can Communication
Central Monitoring And Control
Bi-directional DC/AC & AC/DC power conversion.
Forced air cooling (with HVAC Assisted) / Liquid Cooling
IP54-rated for outdoor durability
Enclosure – Stable performance in all conditions
Battery Energy Storage Solution (BESS) — C&I (125kW/261kWh)
Smart Control
Intelligent EMS Real-time monitoring & optimized energy management
Solar Integration
Photovoltaic Energy Storage Store solar power efficiently for smarter usage
Commercial Grade
Commercial Energy Storage Reliable large-scale energy support for businesses
Power Security
Backup Power Supply Continuous energy backup during outages
Customizable Solution
INV BESS 125kW / 261kWh
C&I Series
- Containerized commercial-scale storage system rated at 125kW/261kWh
- Lithium Iron Phosphate (LFP) prismatic cells, 3.2V/314Ah per cell
- Battery module configuration of 1P5S with 166.4V nominal module voltage
- Rack configuration of 5 modules per rack (1P260P system, 260 total cells)
- Rated voltage of 832V with operating range of 650V–936V
- Typical charge/discharge duration of 2 hours at 0.5C max C-rate
- 90% typical depth of discharge with 235kWh usable energy
- Round-trip efficiency (RTE) of 85%
- Active liquid cooling using 50% ethylene glycol + 50% water coolant mix
- Auxiliary power consumption of max 4kW for thermal management
- Battery Management System with Pack BMU + Rack BMS architecture
- Comprehensive protection: OV/UV/OC/OT (over-voltage, under-voltage, over-current, over-temperature)
- Fire detection via heat and smoke sensors with automatic aerosol-based suppression
- Communication via Modbus TCP/IP for building energy management integration
- IP54-rated cabinet protection, total system weight up to 2700kg
- Operating ambient temperature of -10°C to 55°C
- Max operating altitude of 3000m (with derating above 2000m)
- Suited for commercial sites needing containerized storage for load-shifting and backup resilience.
Key Features
Powering Smarter Energy for a Sustainable Tomorrow
Get in Touch
