Energy Storage Solution (ESS) - Wall Mount
Cell-level Voltage, Current & Temperature Monitoring With Soc Reporting.
Supports Parallel Connection Up To 16 Units.
Ip54-rated Enclosure For Outdoor Protection.
Rs485, Can & Rs232 Communication.
Built-in 3.5 Inch Lcd Screen For Real-time Monitoring
Active Cell Balancing - Optimized Performance & Longer Battery Life.
Complete Safety Protection – Over-temp, Overcharge, Over-discharge & Short-circuit Protection.
Bluetooth Connectivity
Energy Storage Solution (ESS) — Wall Mount (5.12kWh)
16 Units
Supports parallel connections
IP 54 Rated
Enclosure for outdoor protections
99% Efficiency
Optimized performance
660V AC Voltage
Stable grid integration
Reliable Operation
Designed for continuous performance
Industrial Grade Design
Built for large-scale applications
Variants
INV ESS 5.12 kWh Wall Mount
Residential Series
- Rechargeable lithium-ion battery in a space-saving wall-mounted enclosure
- Rated voltage of 51.2V with 100Ah capacity, delivering 5.12kWh rated energy
- Charge-discharge rate of 0.5C with 80% depth of discharge
- Max continuous charge and discharge current of 50A each
- LFP prismatic cell type (3.2V, 100Ah) with active cell balancing across 16S1P configuration
- Charge temperature range of 0°C to 50°C (<85% RH), discharge -20°C to 60°C
- Cell-level BMS monitoring: voltage, current, temperature, and SOC/SOH reporting
- Operating temperature range of -20°C to 60°C
- Automatic emergency shutdown logic on over-current, over-temperature, or fault detection
- Supports parallel connection of up to 16 units for capacity expansion
- Operating voltage range of 40V–58.4V (±0.5V)
- IP54-rated enclosure suitable for outdoor installation
- Built-in 3.5-inch LCD screen for real-time status monitoring
- Bluetooth connectivity for mobile app-based diagnostics
- Compact cell weight of 2.1kg per cell within the pack assembly
- Backed by a 5-year warranty (0.5C charge/discharge, 80% DoD at 25°C)
- Ideal for homeowners wanting discreet, space-saving battery storage alongside a hybrid inverter.
