Hybrid OGH Series
Built-In Anti-Dust Kit
Battery Independent Design
Built-In Feed-In Grid Function
Built-In BMS Communication Port
Maximum Charging Current 100A/120A (Based On Models)
Wide PV Input Range (Starts From 30VDC for 1.5K/3K/4K Models)
Battery Equalization Function (Optimize Performance & Extend Lifecycle)
Built-In WiFi With APP For Mobile Monitoring and OTA Firmware Upgrade
Hybrid-OGH Series — Single Phase (1.5kW–6.2kW)
1500 V
Max. PV Input Voltage
99 %
Max. Efficiency
MPPT
Solar Charging
Wide PV
Input Range
Built-in WiFi
Smart Monitoring
Pure Sine Wave
Output
SINGLE PHASE
INV-OGH-1.5KW-12V INV-OGH-3.0KW-24V INV-OGH-4.0KW-24V INV-OGH-5.0KW-24V INV-OGH-5.0KW-48V INV-OGH-6.2KW-48V
Residential Series
- Single-phase hybrid inverter series across 6 models (1.5kW to 6.2kW)
- Battery voltage options of 12VDC, 24VDC, and 48VDC depending on model
- AC input voltage of 230VAC with selectable range: 170–280VAC (PCs) / 90–280VAC (home appliances)
- Output power ranging from 1500VA to 6200VA, with dual AC output configurations
- Surge power capacity from 3000VA up to 12,400VA
- Peak efficiency of 93% with pure sine wave output
- Fast transfer time: 10ms for computers, 20ms for home appliances
- MPPT solar charging with an array power support up to 6500W
- Maximum PV array open circuit voltage up to 500VDC
- MPPT operating voltage range as wide as 30–450VDC (min. 60–100VDC without battery)
- Max solar charge current up to 100A, max AC charge current up to 100A
- Max total charge current up to 120A, depending on model
- Floating charge voltage precision-tuned per battery voltage class (13.5V/27V/54V)
- Built-in feed-in grid function and BMS communication port
- Battery equalization function to optimize performance and extend the lifecycle
- Built-in WiFi with app-based monitoring and OTA firmware upgrades
- Communication via RS232/RS485(BMS)/WiFi
- Operating humidity range of 5–95% RH (non-condensing)
- Operating temperature of -10°C to 50°C, storage up to 60°C
- Compact dimensions from 357x288x90mm to 435x300x115mm, weighing 6.6–10.4kg
- Perfect for homes seeking solar-plus-battery backup with grid feed-in flexibility.
Applications
- Residential solar systems
- Small commercial setups
- Backup power for offices or shops
- Remote homes or rural electrification projects
- Hybrid systems with energy storage and grid support
Residential Rooftops
- Ideal for small to medium-sized homes
Shops & Offices
- Reduce electricity costs efficiently
Farmhouses & Villas
- Reliable and clean solar power
Net-Metering Systems
- DISCOM compliant integration
CERTIFIED SAFETY
- IEC 62109-1 / 2 compliant
- International safety standards
GRID READY
- IEC 61727 certified
- Reliable grid connectivity
BIS CERTIFIED
- India compliance approved
- Built for local standards
CE & EMC COMPLIANT
- Electromagnetic compatibility
- Reliable and stable operation
Technical Highlights
(Refer to datasheet for detailed specifications.)
