Single Phase Hybrid Inverter LV

Single Phase Hybrid Inverter (LV) — INV EU 3kW–8kW/48V

Single-phase hybrid inverter series across 5 models (3kW to 8kW)
Compatible with lead-acid or lithium-ion batteries with a self-adapting BMS charging strategy
Battery voltage range of 20–30V (3kW model) or 40–60V (3.6–8kW models)
Max charging/discharging current from 90A to 190A, depending on the model
Max PV access power up to 16,000W, max PV input power up to 12,800W
Max PV input voltage of 500V, start-up voltage of 125V
MPPT voltage range of 150–425V with up to 2 MPPT trackers/2 strings
Max operating PV input current up to 26+26A
Rated AC output up to 8000W with max apparent power up to 8800VA
Rated input/output voltage range of 220/230V (0.85Un–1.1Un)
Grid frequency support of 50/45–55Hz, 60/55–65Hz
Max efficiency of 97.60%, Euro efficiency of 97.00%, MPPT efficiency >99%
THD below 3% at nominal power, DC injection current below 0.5% In
Comprehensive protection: DC reverse polarity, AC overcurrent, thermal, arc fault (optional), islanding, RCD detection, surge (Type II DC/AC)

Communication via RS485/RS232/CAN with GPRS/WiFi/Bluetooth/4G/LAN monitoring
DG synchronization capability with a colorful touch LCD display
AC couple option to retrofit existing solar systems
6 configurable time periods for battery charging/discharging
Supports up to 16 units in parallel for on-grid & off-grid operation
IP65 ingress protection rating, non-isolated inverter topology
Operating temperature range of -40°C to 60°C (derating above 45°C)
Natural or intelligent air cooling, depending on model, weighing 17.6–26.8kg
Compliant with IEC 61727, IEC 62116, EN 50549, NRS 097, VDE-AR-N 4105, BIS standards
5-year standard warranty (site-dependent)
Suited for homeowners transitioning to solar-plus-storage with reliable backup power.

Residential Rooftops

Shops & Offices

Farmhouses & Villas

Net-Metering Systems

CERTIFIED SAFETY

GRID READY

BIS CERTIFIED

CE & EMC COMPLIANT

Technical Highlights

(Refer to datasheet for detailed specifications.)

Key Features

Single phase hybrid inverter series across 5 models (3kW to 8kW).
Compatible with lead-acid or lithium-ion batteries with a self-adapting BMS charging strategy.
Battery voltage range of 20–30V (3kW model) or 40–60V (3.6–8kW models).
Max charging/discharging current from 90A to 190A, depending on the model.
Max PV access power up to 16,000W, max PV input power up to 12,800W.
Max PV input voltage of 500V, start-up voltage of 125V.
MPPT voltage range of 150–425V with up to 2 MPPT trackers/2 strings.
Max operating PV input current up to 26+26A.
Rated AC output up to 8000W with max apparent power up to 8800VA.
Rated input/output voltage range of 220/230V (0.85Un–1.1Un).
Grid frequency support of 50/45–55Hz, 60/55–65Hz.
Max efficiency of 97.60%, Euro efficiency of 97.00%, MPPT efficiency >99%.
THD below 3% at nominal power, DC injection current below 0.5% In.
Comprehensive protection: DC reverse polarity, AC overcurrent, thermal, arc fault (optional), islanding, RCD detection, surge (Type II DC/AC).
Communication via RS485/RS232/CAN with GPRS/WiFi/Bluetooth/4G/LAN monitoring.
DG synchronization capability with a colorful touch LCD display.
AC couple option to retrofit existing solar systems.
6 configurable time periods for battery charging/discharging.
Supports up to 16 units in parallel for on-grid & off-grid operation.
IP65 ingress protection rating, non-isolated inverter topology.
Operating temperature range of -40°C to 60°C (derating above 45°C).
Natural or intelligent air cooling, depending on model, weighing 17.6–26.8kg.
Compliant with IEC 61727, IEC 62116, EN 50549, NRS 097, VDE-AR-N 4105, BIS standards.
5-year standard warranty (site-dependent).
Suited for homeowners transitioning to solar-plus-storage with reliable backup power.
