Three Phase Hybrid Inverter LV

Three Phase Hybrid Inverter (LV) — INV(EU) 5kW–20kW/48V

Three-phase hybrid inverter series across 7 models (5kW to 20kW)
Compatible with lead-acid or lithium-ion batteries, self-adapting BMS charging
Battery voltage range of 40–60V with charging current from 120A to 350A
Max PV access power up to 40,000W, max PV input power up to 32,000W
Max PV input voltage of 800V, start-up voltage of 160V
MPPT voltage range of 160–650V with up to 2 MPPT trackers/2 strings
Compliant with IEC 61727, IEC 62116, EN 50549, VDE-AR-N 4105, and BIS standards
Rated AC output up to 20,000W with max apparent power up to 22,000VA
Rated voltage range of 220/380V or 230/400V, adjustable power factor 0.8 leading–lagging
Max efficiency of 97.60%, Euro efficiency of 97.00%, MPPT efficiency >99%
Full protection suite matching LV single-phase series, plus 3-phase grid connection (3L+N+PE)

THD below 3% (or 2.5% at rated power on select models)
DG synchronization with support for multiple batteries in parallel
Max charging/discharging current of 350A for high-capacity battery banks
6 configurable time periods for battery charging/discharging
Supports up to 10 units in parallel for on-grid & off-grid operation
Three-phase hybrid inverter series across 7 models (5kW to 20kW)
100% unbalanced output — each phase can deliver up to 50% rated power independently
IP65 rated, intelligent air cooling, operating altitude up to 3000m
Operating temperature of -40°C to 60°C, noise level ≤55dB (≤30dB on lower models)
Max operating PV input current up to 54+54A
5-year standard warranty (site-dependent)
Ideal for larger homes and small commercial setups with three-phase electrical loads.

Residential Rooftops

Shops & Offices

Farmhouses & Villas

Net-Metering Systems

CERTIFIED SAFETY

GRID READY

BIS CERTIFIED

CE & EMC COMPLIANT

Technical Highlights

(Refer to datasheet for detailed specifications.)

Key Features

Three phase hybrid inverter series across 7 models (5kW to 20kW).
Compatible with lead-acid or lithium-ion batteries, self-adapting BMS charging.
Battery voltage range of 40–60V with charging current from 120A to 350A.
Max PV access power up to 40,000W, max PV input power up to 32,000W.
Max PV input voltage of 800V, start-up voltage of 160V.
MPPT voltage range of 160–650V with up to 2 MPPT trackers/2 strings.
Max operating PV input current up to 54+54A.
Rated AC output up to 20,000W with max apparent power up to 22,000VA.
Rated voltage range of 220/380V or 230/400V, adjustable power factor 0.8 leading–lagging.
Max efficiency of 97.60%, Euro efficiency of 97.00%, MPPT efficiency >99%.
THD below 3% (or 2.5% at rated power on select models).
Full protection suite matching LV single-phase series, plus 3-phase grid connection (3L+N+PE).
DG synchronization with support for multiple batteries in parallel.
Max charging/discharging current of 350A for high-capacity battery banks.
6 configurable time periods for battery charging/discharging.
Supports up to 10 units in parallel for on-grid & off-grid operation.
100% unbalanced output — each phase can deliver up to 50% rated power independently.
IP65 rated, intelligent air cooling, operating altitude up to 3000m.
Operating temperature of -40°C to 60°C, noise level ≤55dB (≤30dB on lower models).
Compliant with IEC 61727, IEC 62116, EN 50549, VDE-AR-N 4105, and BIS standards.
5-year standard warranty (site-dependent).
Ideal for larger homes and small commercial setups with three phase electrical loads.
