Three Phase Solar GTI
IP 65 Rated
AFCI (Optional)
Patented Cooling Design
Unique H6 Topology Prevents Leakage Current
Wide Range Of AC Grid Voltage Up To 290 Volts
Within 24 Hours Replacement, 365 Days Up-time
Three Phase Solar GTI — INV TP Series (5kW–25kW)
Patented Cooling Design
Advanced thermal design for stable operation
Wide AC Grid Voltage Range
Supports grid voltage up to 290V
24H Replacement Support
365-day uptime support
Unique H6 Topology
Prevents leakage current
AFCI (Optional)
Advanced safety option
Dual Cooling System
Force + natural cooling for better performance
INV TP Series
INV 5.0 TP INV 15.0 TP INV 6.0 TP INV 18.0 TP INV 8.0 TP INV 20.0 TP INV 10.0 TP INV 25.0 TP INV 12.0 TP
Residential Series
- Three-phase grid-tied inverter series spanning 5kW to 25kW capacities (10 models)
- Recommended max PV input power from 7500Wp to 33,000Wp
- Max PV input voltage of 1050V (up to 1000V on higher models), nominal 850VDC
- MPPT voltage range of 160–850VDC with 1–2 independent MPPT inputs
- Max PV input current up to 36A, DC short-circuit current up to 48A
- Nominal AC output power from 5000W to 25,000W at 400VAC, 50/60Hz
- Achieves max efficiency up to 99.50% and MPPT efficiency of 99.90%
- THD below 5% at rated power (below 1.5% for higher-capacity models)
- Adjustable power factor from 0.8 leading to 0.8 lagging
- Complete protection: grid monitoring, DC reverse polarity, short-circuit, leakage current, surge, anti-islanding, and residual current protection
- Transformerless topology, wall-mounted installation, IP65 rated per IEC 60529
- Smart cooling with LCD display, WiFi/RS485/GPRS communication
- MC4-compatible DC connectors for simplified installation
- Operating temperature range of -25°C to 60°C, humidity up to 95% (non-condensing)
- Max operating altitude of 3000m without power derating
- Dimensions from 420x370x130mm (5–10kW) to 520x510x160mm (higher capacity)
- Compliant with CE, EN/IEC 61000, IEC 62109, BIS, IEC 60068-2, VDE-AR-N 4105
- 8-year warranty
- Suited for larger homes, villas, and light-commercial rooftop solar projects.
