Hybrid OGH MAX Series
Built-in anti-dust kit
Increased PV Power
7" Touchscreen HMI LCD
Status indication with RGB lights
Maximum PV input current 27A
Supports USB On-the-Go function
Built-in BMS communication port
Battery independent design
Dual outputs and dual inputs for smart energy management
Built-in WiFi with APP for mobile monitoring and OTA firmware upgrade
External CT sensor to guarantee 100% self-consumption
Built-in meter calibration for optimized system operation
Hybrid-OGH MAX Series — Single Phase (8kW–11kW)
Pure Sine Wave Output
Clean & Stable Power
MPPT Solar Charging
Maximum Solar Efficiency
Wide PV Input Range
Flexible Solar Compatibility
Maximum Charging Current
Fast Power Charging
Built-in WiFi
Remote System Monitoring
Battery Independent Design
Flexible Energy Setup
SINGLE PHASE
INV-OGH-8.0KW-48V INV-OGH-10.0KW-48V INV-OGH-11KW-48V
Residential Series
- Higher-capacity single-phase hybrid inverter series (8kW, 10kW, 11kW models)
- Parallel capability for up to 6 units for scalable power output
- AC input voltage of 230VAC with selectable range: 170–280VAC / 90–280VAC
- Surge power from 16,000VA to 22,000VA, peak efficiency of 93%
- Pure sine wave output with 10–20ms transfer time
- 48VDC battery architecture with floating charge voltage of 54VDC
- MPPT solar charging with array power up to 13,000W (6500W x 2 channels)
- MPPT operating voltage range of 90–450VDC
- Max PV input current of 27A x 2 (max 40A), max PV array open circuit voltage of 500VDC
- Max AC and total charge current up to 150A
- Built-in anti-dust kit for extended equipment life in dusty environments
- 7" touchscreen HMI LCD with RGB status indication lighting
- Dual outputs and dual inputs for smart, prioritized energy management
- Built-in WiFi with app monitoring and OTA firmware upgrade support
- External CT sensor for 100% self-consumption optimization
- Built-in meter calibration for fine-tuned system operation
- Communication via USB/RS232/RS485/WiFi/Dry-contact
- Operating humidity of 5–95% RH, temperature range -10°C to 50°C
- Compact footprint (158.4 x 503.6 x 530.8mm) at 20kg weight
- CE compliance safety certification
- Designed for larger homes and small businesses with higher daytime energy consumption.
Applications
- Residential solar hybrid systems
- Small commercial setups
- Smart homes with energy storage
- Remote locations with unstable grid supply
- Offices with solar + battery backup
Residential Rooftops
- Ideal for small to medium-sized homes
Shops & Offices
- Reduce electricity costs efficiently
Farmhouses & Villas
- Reliable and clean solar power
Net-Metering Systems
- DISCOM compliant integration
CERTIFIED SAFETY
- IEC 62109-1 / 2 compliant
- International safety standards
GRID READY
- IEC 61727 certified
- Reliable grid connectivity
BIS CERTIFIED
- India compliance approved
- Built for local standards
CE & EMC COMPLIANT
- Electromagnetic compatibility
- Reliable and stable operation
Technical Highlights
(Refer to datasheet for detailed specifications.)
Key Features
