Energy Storage Solution (ESS) - Stack Mount
Cell-level Voltage, Current & Temperature Monitoring With Soc Reporting.
Up To 6 Batteries Per Stack & Up To 16 Batteries In Parallel.
IP54-rated Enclosure For Outdoor Protection.
Rs485, Can & Rs232 Communication
Built-in 3.5 Inch Lcd Screen For Real-time Monitoring
Active Cell Balancing - Optimized Performance & Longer Battery Life.
Complete Safety Protection – Over-temp, Overcharge, Over-discharge & Short-circuit Protection.
Bluetooth Connectivity
Energy Storage Solution (ESS) — Stack Mount (5.12kWh)
Modular Stacking Architecture
Flexible Capacity Expansion
IP 54 Rated
Enclosure for outdoor protections
Battery Management System (BMS)
Intelligent Safety Protection
Solar + Storage Integration
Optimized Energy Utilization
Variants
INV ESS 5.12 kWh Stack Mount
Residential Series
- Rechargeable lithium-ion battery in a modular, stackable enclosure design
- Shares the same 51.2V, 100Ah LFP cell foundation as the wall-mount variant (5.12kWh)
- Charge-discharge rate of 0.5C with 80% depth of discharge
- Max continuous charge and discharge current of 50A each
- Operating voltage range of 40V–58.4V (±0.5V)
- Up to 6 battery units stackable per tower, with up to 16 batteries supported in parallel
- Cell-level BMS monitoring with SOC reporting across voltage, current, and temperature
- Active cell balancing for optimized performance and extended battery life
- Full protection: over-temperature, overcharge, overdischarge, short-circuit protection
- Communication via RS485, CAN, and RS232 for multi-platform compatibility
- Built-in 3.5-inch LCD screen for real-time monitoring
- Bluetooth connectivity for remote diagnostics and firmware updates
- IP54-rated enclosure for both indoor and outdoor deployment
- Charge/discharge temperature range of 0°C to 50°C / -20°C to 60°C respectively
- Backed by a 5-year warranty (0.5C charge/discharge, 80% DoD at 25°C)
- Suited for homes, utility rooms, and garages needing scalable storage capacity in a compact footprint.
