Energy Storage Solution - C&I
Cell-level Voltage, Current & Temperature Monitoring With Soh Reporting.
Supports Modbus Tcp/ip, Rs485 & Can Communication
IP54-rated Enclosure For Outdoor Protection.
High-performance System Design For Stable Continuous Operation.
Efficient Thermal Management With Cooling Fans On Each Module.
Complete Safety Protection – Over-temp, Overcharge, Over-discharge & Short-circuit Protection.
Energy Storage Solution (ESS) — C&I Series (51.2kWh–176.84kWh)
1500 V
Max. Battery Voltage
99 %
Peak Efficiency
24/7
Technical Support
Zero
Maintenance Need
Smart
Battery Indicator
Short-circuit
Protection
High
Battery Backup
Compact
Space Saving Design
Customizable Solution
INV-ESS-512-100Ah INV-ESS-563.2-314Ah INV-ESS-665.6-100Ah
C&I Series
- Rack-based commercial and industrial storage system across 3 configurations
- Rated voltage options: 512V, 563.2V, and 665.6V depending on configuration
- Rated capacity of 100Ah or 314Ah using LFP prismatic cells (3.2V per cell)
- Rated energy spanning 51.20kWh, 176.84kWh, and 66.56kWh across models
- Backed by a 5-year warranty (0.5C charge/discharge, 80% DoD at 25°C)
- Charge-discharge rate of 0.5C with 80% depth of discharge
- Max continuous charge and discharge current up to 157A (mid-capacity model)
- Operating voltage range as wide as 448.8V–759.2V, depending on configuration
- Rack configuration of 10 to 13 packs per system (165:1P to 16S1P pack structure)
- Forced air cooling with dedicated fans on each battery pack for thermal stability
- Cell-level BMS monitoring with SOH (State of Health) reporting and degradation tracking
- Safety logic executes an automatic emergency shutdown on fault detection
- Full protection: over-temperature, overcharge, overdischarge, short-circuit
- Communication via Modbus TCP/IP, RS485, and CAN for BEMS/SCADA integration
- IP54-rated enclosure for outdoor commercial deployment
- Single rack configuration per cabinet, expandable per site requirement
- Backed by a 5-year warranty (0.5C charge/discharge, 80% DoD at 25°C)
- Designed for commercial and industrial facilities aiming to reduce peak demand charges.
