Three Phase Hybrid Inverter HV
DG Synchronization
800 Battery Voltage Range
High Voltage Battery, Higher Efficiency
DC Couple and AC Couple To Retrofit Exiting Solar System
Max. 10 pcs Parallel For On-Grid & Off-Grid Operation; Support Multiple Batteries Parallelly
100% Unbalanced Output, Each Phase: Max. output Up To 50% Rated Power
Three Phase Hybrid Inverter (HV) — C&I Series (30kW–80kW)
1500V
High PV Input
3125 kVA
High Power Output
660V
Stable AC Voltage
99%
Max Efficiency
Variants
INV(EU)-30kW/40kW/50kW/60kW/80kW
C&I Series
- Commercial/industrial three-phase hybrid inverter series (30kW to 80kW)
- High-voltage lithium-ion battery compatibility, voltage range of 160–1000V
- Max charging/discharging current from 50+50A to 80+80A
- Max PV access power up to 160,000W, max DC input power up to 128,000W
- Max DC input voltage of 1000V, MPPT voltage range of 150–850V
- Multiple independent MPPT trackers (up to 6 strings on 80kW model)
- Max operating PV input current up to 54A x 6 strings
- Rated AC output up to 80,000W with max apparent power up to 121.3/115.9kVA
- Peak power up to 2.5x rated power (off-grid) for 10 seconds
- Max efficiency of 98.70% (Euro efficiency 97.00–98.10%)
- THD below 3% at nominal power, DC injection current <0.5% In
- Full protection suite: grid monitoring, DC reverse polarity, arc fault, RCD, Type II surge (DC/AC)
- Three-phase grid type with adjustable power factor 0.8 leading–lagging
- 800V battery voltage range enables higher system efficiency vs. LV alternatives
- DC and AC couple options for retrofitting existing solar installations
- Supports up to 10 units in parallel with multiple batteries in parallel
- 100% unbalanced output capability, each phase up to 50% rated power
- Intelligent air cooling, IP65 rated, operating altitude up to 3000m
- Communication via RS485/CAN, monitored via GPRS/WiFi/Bluetooth/4G/LAN
- Wall-mounted installation, operating temperature -40°C to 60°C
- Compliant with IEC 61727, IEC 62116, EN 50549, VDE-AR-N 4105, and BIS standards
- 5–10 year warranty depending on configuration
- Built for commercial and industrial facilities requiring high-voltage, large-scale solar-storage integration.
Residential Rooftops
- Ideal for small to medium-sized homes
Shops & Offices
- Reduce electricity costs efficiently
Farmhouses & Villas
- Reliable and clean solar power
Net-Metering Systems
- DISCOM compliant integration
CERTIFIED SAFETY
- IEC 62109-1 / 2 compliant
- International safety standards
GRID READY
- IEC 61727 certified
- Reliable grid connectivity
BIS CERTIFIED
- India compliance approved
- Built for local standards
CE & EMC COMPLIANT
- Electromagnetic compatibility
- Reliable and stable operation
Technical Highlights
(Refer to datasheet for detailed specifications.)
